TERA HARZ C&B – TC-80 DP
Per la produzione di ponti e corone permanenti
Tera Harz C&B (TC80 – Dental Permanent) è il primo materiale al mondo indicato per la stampa 3D di elementi permanenti, dalla corona singola all’arcata completa, su denti naturali o impianti. Grazie alle sue proprietà, supera di fatto i limiti di applicazione comuni a tutti gli altri materiali ad oggi sul mercato per la produzione di C&B (corone e ponti).
Le sue caratteristiche fisiche e tecniche, come durezza e modulo elastico, molto simili alla zirconia, permettono di ottenere manufatti altamente performanti attraverso un metodo di produzione che elimina gli sprechi e di massima efficienza.
Compatibilità
Graphy Tera Harz C&B è compatibile con tutte le stampanti 3D a 405 nm.
Indicazioni d’uso:
Ponti e corone permanenti, dalla corona singola all’arcata completa, su denti naturali o su impianti.
Inlay e onlay – faccette – splintaggi
Tera Harz C&B DM classe II A
Tonalità:
A1, A2, A3
CONTATTACI PER INFORMAZIONI
Specifiche tecniche del manufatto stampato con Tera Harz C&B
| Proprietà del manufatto stampato |
Unità |
C&B |
ISO |
|
| Colore | A1, A2, A3 | |||
| Densità | g/cm³ @ 25 ℃ | 1.076 ± 0.02 | ||
| Viscosità | cps @ 25 ℃ | 2000 ± 300 | BrookField | |
| Contenuto solido | % @ 80 ℃ x 1h | ≥ 98 | ||
| Durezza Shore (D) | ≥ 90 | |||
| Resistenza alla flessione bi-assiale | Mpa | ≥ 350 | ISO 6872 | |
| Resistenza alla flessione | Mpa | ≥ ISO Standard 160, Proprietary Standard 220 | ISO 10477 | |
| Modulo elastico | Mpa | ≥ ISO Standard 3500, Proprietary Standard 4500 | ISO 10477 | |
| Assorbimento acqua | μg/mm³ | 18.9 | ISO 10477 | |
| Solubilità in acqua | μg/mm³ | 0.5 | ISO 10477 |
DOWNLOAD
PUBBLICAZIONI TC80
Case Study e Applicazioni Reali
PUBBLICAZIONI TC80
Case Study e Applicazioni Reali
CONTATTACI PER INFORMAZIONI
